Vertical Ring Die Pellet Tshuab
Vertical ring die pellet tshuab, zoo pellet zeb los tsim cov pellets los ntawm cov khoom ntim qis xws li: txiv laum huab xeeb plhaub, paj noob hlis, husk., Thiab lwm yam cov khoom siv yuav yooj yim nias rau hauv lub nplhaib tuag.Tau tsis siv neeg roj lubrication system rau bearings hauv ncej thiab rollers.Ring tuag tuaj yeem ua haujlwm nrog ob sab, lub neej ntev dua.
Hauj lwm lawm
Vertical Ring Die Pellet Tshuab
Vertical ring tuag pellet tshuab yog ib hom ntawm pellet zeb. Lub hauv paus thav duab, lub cev muaj zog, txo qis, lub hauv paus tseem ceeb, cov menyuam, lub nplhaib tuag, pub chute, thiab cov roj nplua nyeem tshuab yog qhov tseem ceeb ntawm lub tshuab. Hom pob zeb pellet no yog qhov tsim nyog los ua cov khoom siv roj av los ntawm cov khoom siv biomass zoo li ntoo, EFB, txiv maj phaub plhaub, sawdust, txhuv husk, txiv laum huab xeeb, paj noob hlis, quav nyab, nyom, thiab lwm yam.
Lub cev muaj zog txuas mus rau tus txo qis los ntawm kev sib txuas, tus txo qis txiav txim siab qhov kev sib hloov ceev ntawm lub hauv paus loj, lub hauv paus tseem ceeb tsav cov menyuam kom tig. Lub cev muaj zog thiab txo qis ua lub zog tsav ntawm lub tshuab tag nrho. Peb lub tshuab xaiv Tuam Tshoj lub npe tshuaj txo kom ntseeg tau tias qhov zoo thiab ua tau zoo ntawm lub tshuab tag nrho.
Sab saum toj ntawm lub hauv paus tseem ceeb yog chav pelletizing, hauv ntu no suav nrog cov menyuam, lub nplhaib tuag, thiab lub tshuab txiav pellet. Rau lub nplhaib ntsug tuag pellet zeb, thaum lub tshuab ua haujlwm lub nplhaib tuag ruaj khov thaum cov menyuam tig, cov menyuam tig tuaj yeem nqa lub zog centrifugal, uas tuaj yeem pab nias cov khoom nyoos rau hauv lub qhov ntawm lub nplhaib tuag. Tias' yog vim li cas nws zeb muaj qhov kom zoo dua nyob rau hauv cov txheej txheem ntawm cov khoom ntom ntom ntom ntom ntom ntom. Vim tias chav pelletizing yog nyob rau sab saum toj ntawm lub hauv paus loj, hom pellet zeb no hu ua lub nplhaib ntsug tuag pellet tshuab.
Vim li cas thiaj xaiv peb lub nplhaib ntsug tuag pellet zeb
1. Vertical structure, centrifugal force hauv chav pelletizing, muaj kev ua tau zoo dua ntawm cov khoom siv raw.
2. Nruab nrog roj lubricate system, tsis siv neeg greasing los tiv thaiv cov kabmob.
3. Ntawm lub nplhaib tuag muaj ob sab qhov, tom qab ib sab tau hnav, tig lub nplhaib tuag kom siv lub qhov nyob rau lwm sab, yog li txuas ntxiv lub neej ntawm lub nplhaib tuag.
4. Ntiv nplhaib tuag nrog qhov tshwj xeeb sib piv sib piv rau cov khoom sib txawv.
5. Gearbox kis tau tus mob system, zoo heev txhim kho cov khoom tsim tau
Ua haujlwm yees duab ntawm lub nplhaib ntsug tuag pellet zeb |
Ntsug nplhaib tuag pellet zeb |
Ntiv nplhaib tuag |
Ntsug ntiv nplhaib tuag pellet zeb kev cov ntaub ntawv
Qauv | TXL 450 | MKX 500 | TIAB SA 560 | MKX 600 | TXL 700 |
Peev Xwm | 600-800Kg/h | 800-1200Kg/teev | 1200-1500Kg/teev | 1500-2000Kg/h | 2000-2500Kg/h |
Fais fab | 55 kwv | 75 kwv | 90 kwv | 132 kwv | 160 Kws |
Ntiv nplhaib tuag sab hauv | 450 hli | 480 hli | 550 hli | 550 hli | 700 hli |
De-hmoov av kiv cua zog | 1.5 Kws | 1.5 Kws | 1.5 Kws | 2.2 Kws | 3 kwv |
Lubricator lub zog | 0.37Kw | 0.37Kw | 0.37Kw | 0.37Kw | 0.37Kw |
Pellet cutter zog | 1.1 Kws | 1.1 Kws | 1.5 Kws | 1.5 Kws | 1.5 Kws |
Cov dej noo | 12-15% | ||||
Raw khoom loj | & lt; 5 hli | ||||
Pellet txoj kab uas hla | 6mm, 8mm, 10mm, 12mm, lossis customized | ||||
Pellet ya raws | 7-9% | ||||
Ntiv nplhaib tuag/cov menyuam kev ntxhib los mos | 20CrMiTi | ||||
Ntiv nplhaib tuag lub neej | Ua cov pellets rau 1000 teev | ||||
Pob loj | 2290*1090*1100 hli | 2300*1110*1490 hli | 2780*1200*1800 hli | 2800*1200*1800 hli | 2850*1310*1990 hli |
Qhov hnyav tag nrho | 2000 Kg | 3000Kg | 5000 Kg | 5400 Kg | 7000 Kg |
